- Ethernet prievadai8*10/100/1000BASE-T PoE RJ-45(Auto-MDI/MDI-X), 2*1G/2.5GBASE-X SFP (The default value is 1G)
- Valdymo prievadai1*RJ-45 Console, 1*Relay
- Serial prievadas1*RS-485, RS-485 signal: D+, D-, Check bit: None, Even, Odd, Space, Mark,Data bit: 5, 6, 7, 8bit, Stop bit: 1, 1.5, 2bit, Baud rate: 300~115200bps, Load capacity: RS-485 port supports,32-point polling environment (128-point could be customized),Direction control: RS-485 adopts automatic data flow control technology
- USB prievadaiUSB3.0
- Pagalbinis nuolatinės srovės išėjimasOFF/12V/24V@2A max
- Init mygtukasShort press to restart the device, Long press >5s to initialize the system
- LED indikatoriai2*PWR, power indicators, 1*ALM, alarm indicator, 2*SFP port indicators
- Dydis163mm*110mm*95.1mm
- Svoris be įpakavimo1.72kg
- Įeinanti įtampaSupport redundant power supply, Power 1 (Main): 12~57V DC, Power 2 (Backup): 12~57V DC
- Energijos sunaudojimas≤250W (Full load including PoE & auxiliary DC)
- MontavimasDIN-rail/Desktop/Wall mounted
- MedžiagaMetal shell
- Persiuntimo režimaiStore and Forward
- Perjungimo talpa26Gbps / non-blocking
- Paketų persiuntimo greitis19.344Mpps
- MAC adresų lentelė16k, support auto learning
- Port Buffer2MB
- Jumbo Frame9kB
- PoE standartasIEEE 802.3af/at/bt
- PoE maitinimo tipasEnd-span
- PoE išdėstymas1/2(+),3/6(-) or 3/6/4/5(+), 1/2/7/8(-)
- PoE biudžetasMode1: 45W max for each port, Mode2: 90W max for port 1, disabled PoE function for port 2, 45W max for ports 3 to 8 each, 240W@48V, 120W@24V, 60W@12V max for whole switch (Including auxiliary DC output)
Išparduoda
10 prievadų komutatorius UTEPO UTP7310S-PSD240-W (pramoninis)
€357.11
- 10 prievadų komutatorius
- 8 x PoE – 1000 mbps prievadai
- 2 x XSFP Uplink 2.5Gb
- 1 x RJ-45 Console
- 1 x RS485
- 1 x USB 3.0
- Pramoninis
Out of stock
Description
Additional information
| Gamintojas |
|---|
