Modelis |
UTP3-GSW2404S-MTP250 |
||
|
Variniai prievadai |
24*10/100/1000Base-T PoE RJ45(Auto-MDI/MDI-X) |
||
|
SFP prievadai |
4*1000 Base-X SFP(Mini-GBIC) |
||
|
Konsolės prievadas |
1*RJ45-R232 serial port(115200,8,N,1) |
||
|
Įjungimo mygtukas |
Short press:restart; |
||
|
>5s Press: restore factory settings. |
|||
|
Tinklo standartas |
IEEE802.3 , IEEE802.3u, IEEE802.3ab, IEEE802.3Z, IEEE802.3X, IEEE 802.1Q, IEEE 802.1p IEEE 802.3ad , IEEE 802.1D, IEEE 802.1X |
||
|
Perjungimo pajėgumas |
56Gbps / non-blocking |
||
|
Paketų perdavimo greitis |
41.7Mpps |
||
|
Perdavimo būdai |
Store and Forward |
||
|
Paketų buferis |
12Mbit |
||
|
MAC adreso lentelė |
16K MAC address table with auto learning function |
||
|
Jumbo Frame |
10K bytes |
||
|
PoE standartas |
IEEE802.3af 15.4W, IEEE802.3at 30W |
||
|
PoE galios metodas |
End-span |
||
|
PoE laido pora |
1/2(+)，3/6(-) |
||
|
Įvesties įtampa |
Internal power adapter |
||
|
AC 100-240V 50/60Hz |
|||
|
Elektros suvartojimas |
<250W (PoE consumption) |
||
|
PoE budget: 230W |
|||
|
Atsparumas viršįtampiams |
6KV |
||
|
Execute: IEC61000-4-5 |
|||
|
ESD atsparumas |
6KV: Contact discharge |
||
|
8KV: Air discharge |
|||
|
Execute: IEC61000-4-2 |
|||
|
Darbinė temperatūra |
-10-50℃ |
||
|
Saugyklos temperatūra |
-40-85℃ |
||
| Drėgmė |
5%-95%(Non-condensing) |
||
|
Matmenys（I×P×A） |
442mm×286mm×44mm |
||
|
Svoris |
3.859kg |
||
|
Sertifikatai |
CE, FCC, ROHS |
||
|
Programinės įrangos parametrai |
|||
|
Sąsajos valdymas |
Logic Interface |
Support port isolation |
|
|
Support port rate settings |
|||
|
Support port storm suppression |
|||
|
Support IEEE802.3x flow control |
|||
|
Support port traffic statistics |
|||
|
Support port adaptation |
|||
|
Loopback detection |
|||
|
VLAN |
VLAN Partition |
VLAN based on port, VLAN based on MAC |
|
|
Private VLAN, multicast VLAN |
|||
|
VLAN Communication |
VLAN intercommunication |
||
|
VLAN isolation |
|||
|
VLAN Port Type |
Access, Trunk, GVRP, QinQ |
||
|
MAC |
Static MAC |
||
|
MAC Black hole |
|||
|
Dynamic MAC |
MAC address aging configuration |
||
|
MAC address learning limit |
|||
|
Multicast MAC |
Static Multicast MAC address |
||
|
Grįžtamojo ryšio apsauga |
STP/RSTP, ERPS v1，v2（G.8032, y.1731 CCM |
||
|
IP funkcijos |
IP address : Classful IP address, classless IP address |
||
|
ARP |
|||
|
IPv6 address configuration |
|||
|
DHCP |
Host DHCP service |
DHCP pool |
|
|
DHCP relay |
DHCP snooping option 82 |
||
|
IGMP funkcijos |
IGMP snooping |
||
|
GMRP |
|||
|
QoS |
Support 802.1p CoS/DSCP priority |
||
|
Support 8-Level priority management for switching |
|||
|
Support WRR, PQ, DRR, WFQ, ACL based on ports and queues |
|||
|
PoE valdymas |
Support total power consumption control |
||
|
Support PoE ON/OFF |
|||
|
Support single port 30W max. Power change and port output priority |
|||
|
Saugumas |
802.1x |
IEEE 802.1X Port/MAC based authentication, Radius |
|
|
Support MAC address auto-learning, aging& filter |
|||
|
Support port isolation, port speed-limited |
|||
|
ACL |
Basic ACL, advanced ACL |
||
|
System Log |
Local system log management |
||
|
Remote System Log Management |
|||
|
Mirroring |
Port mirroring |
||
|
Sistemos valdymas ir priežiūra |
Support WEB management, configuration through Telnet, SSH, Tracert v4 |
||
|
SNMPv1/v2/v3 management |
|||
|
NTP |
|||
|
Link layer discovery protocol (LLDP) |
|||
|
IPv6 |
Dual IPv4/IPv6 stack |
||
|
Ping IPv6, WEB IPv6 |
|||
|
DHCPv6 snooping, DHCPv6 client |
|||
|
IPv6 ACL, IPv6 SSH |
|||
|
IPv6 neighbor discovery (ND) |
|||
Išparduoda
24 prievadų, 24 PoE komutatorius UTEPO UTP3-GSW2404S-MTP250
€468.73
- 24 x Gigabit PoE RJ45 jungtys
- 4 x Gigabit uplink SFP jungtys
- Sustiprinta Ethernet išmanioji galios perdavimo funkcija (POE+)
- Išvesties galia siekia 30W kiekviename prievade
Out of stock
Description
Additional information
| Weight | 4.136 kg |
|---|---|
| Gamintojas |
