Modelis |
UTP7624GE-POE-L3 |
|
Downstream prievadai |
24* 10/100/1000Base-T PoE |
|
Uplink prievadai |
4*10GBase-X SFP+ |
|
Tinklo standartas |
IEEE802.3 , IEEE802.3u, IEEE802.3ab, IEEE802.3Z, IEEE802.3X, IEEE 802.1Q IEEE 802.1p IEEE 802.3ad , IEEE 802.1D, IEEE 802.1X |
|
Perjungimo pajėgumas |
128Gbps |
|
Paketų perdavimo greitis |
96Mpps |
|
Perdavimo būdai |
Store and Forward |
|
Paketų buferis |
12M |
|
MAC adresų lentelė |
16K |
|
PoE standartas |
802.3af/at(PSE) |
|
PoE galios metodas |
End-span |
|
PoE laido pora |
1/2(+), 3/6(-) |
|
PoE išvesties galia |
54V DC , 30 watts max |
|
PoE galia |
390 watts max |
|
Atsparumas viršįtampiams |
6KV Execute: IEC61000-4-5 |
|
ESD atsparumas |
6KV Contact discharge |
|
8KV Air discharge |
|
|
Execute: IEC61000-4-2 |
|
|
Išvesties įtampa |
100~240V AC, 50/60Hz |
|
Darbinė temperatūra |
-10-50℃ |
|
Saugyklos temperatūra |
-40-85℃ |
|
Atsparumas drėgmei |
5%-95% |
|
Išmatavimai (I×P×A) |
442mm×305mm×44.5mm |
|
Svoris |
4.35kg |
|
Sertifikatai |
CE, FCC, ROHS |
|
Programinė įranga |
|
|
Prievado valdymas |
Support port enabling and disabling |
|
Support port speed settings |
|
|
Support port full-duplex mode |
|
|
Support IEEE802.3x flow control |
|
|
Support Jumbo Frame |
|
|
Support port name modification |
|
|
VLAN |
Support of 4K VLAN |
|
support 802.1Q VLAN protocol |
|
|
support QINQ |
|
|
support GVRP dynamic VLAN register |
|
|
Support VLAN based on portprotocolMAC |
|
|
Paslaugos kokybė |
Support COS classification base on 802.1p |
|
support QoS base on DSCP |
|
|
Support 8 priority queues |
|
|
Queue scheduling: SP, WRR, SP+WRR |
|
|
Support 802.1p CoS/DSCP priority |
|
|
Transliacijų valdymas |
Support SNMPV1 / V2 / V3 protocols |
|
Support IGMP Snooping |
|
|
support MLD-snooping |
|
|
POE valdymas |
Support Total Power Control |
|
Support PoE On Off |
|
|
Support single-port 30W output，Output port and priority |
|
|
Saugumo charakteristika |
Supports IP, MAC, port, VLAN binding combinations |
|
Support MAC address auto-learning, aging and filtration |
|
|
Support port isolation, port speed limit |
|
|
Support STP RSTP MSTP，Fast-Ring |
|
|
Support 5 groups of link aggregation |
|
|
support LLDP ,Smart-Link ,DLDP |
|
|
Support 802.1X |
|
|
ACL |
support base on source-MAC, target-MAC, protocal-classify, source-IP, target-IP, L4 ports-number |
|
support time-range management |
|
|
Sistemos valdymas |
Web-based GUI and CLI management |
|
Support FTP / TFTP / HTTP load upgrade |
|
|
Support traffic statistics |
|
|
Support MAC address table query |
|
|
Support IP address, DNS server modifications |
|
|
Support user name and password modification |
|
|
Support for history, log management |
|
|
Support System Configuration Backup |
|
|
Support to recover the default factory settings on reboot |
|
|
L3 valdymas |
support IPV4 static route setup |
|
support RIP V1/2 on IPV4 |
|
|
support OSPF V1/V2 |
|
|
support ISIS on IPV4 |
|
|
support BGP on IPV4 |
|
|
Support static ARP Add,delete,burn-in time sutup/check |
|
|
Support static NDAdd,delete,burn-in time sutup/check |
|
|
Support VRRP V1/2/3 virtual redundant route protocol |
|
|
Support group-brocasting PIM,IGMP V1/V2/V3,MLD(IPV4) |
|
|
Support DHCP client,server |
|
|
Support relay repeater,DHCP snooping |
|
|
Support duplex transfer check mechanism |
|
Išparduoda
24 prievadų, 24 PoE komutatorius UTEPO UTP7624GE-POE-L3
€561.17
- 24 x PoE Gigabit downlink Ethernet prievadai
- 4 x 10 Gigabit uplink SFP prievadai
- Palaiko One-key CCTV/LOCK/ONLINE/RING
- Palaiko IEEE 802.3 af/at
- Palaiko Web layer-3 tinklo ir PoE valdymą
Out of stock
Description
Additional information
| Weight | 5.1 kg |
|---|---|
