- Judesio aptikimas 2.0
- Žmogaus / transporto priemonės analizė
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
- Perimetro apsauga
- Žmogaus / transporto priemonės analizėUp to 8-ch, for channel 1/2/3/4/17/18/19/20 only
- Įrašymas
- Vaizdo suspaudimasH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Užkodavimo raiška
When 1080p Lite mode is not enabled:
4 MP Lite/1080p/720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode is enabled:
4 MP Lite/1080p Lite/720p Lite/VGA/WD1/4CIF/CIF
- Kadrų dažnis
Main stream:
When 1080p Lite mode is not enabled:
For 4 MP stream access:
4 MP Lite@15 fps; 1080p Lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
For 1080p stream access:
1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25fps (P)/30 fps (N)
For 720p stream access:
720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
When 1080p Lite mode is enabled:
4 MP Lite@15 fps; 1080p Lite/720p Lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
Sub-stream:
WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)
- Video Bitrate32 Kbps to 6 Mbps
- Dvibugas srautasSupport
- Srauto tipasVideo, Video & Audio
- Garso suspaudimasG.711u
- Garso bitų greitis64 Kbps
- Vaizdas ir garsas
- IP vaizdo įrašų įvestis
16-ch (up to 48-ch)
Up to 6 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
- Analoginė vaizdo įrašų įvestis
32-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- Įeinantis pralaidumas200 Mbps
- Išeinantis pralaidumas160 Mbps
- HDTVI Input4 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
- AHD Input4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input1080p25, 1080p30, 720p25, 720p30
- CVBS InputPAL/NTSC
- CVBS išvestis1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
- HDMI 1 Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- HDMI 2 Output1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- VGA išvestis1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Vaizdo išvesties režimasHDMI1/VGA simultaneous output, HDMI2/VGA independent output
- Garso įvestis4-ch, RCA (2.0 Vp-p, 1 KΩ)
- Garso išvestis1-ch, RCA (Linear, 1 KΩ)
- Dvipusis greitis1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent)
- Sinchroninis atkūrimas16-ch
- Internetas
- Nuotolinis prisijungimas128
- ProtokolaiTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP
- Tinklo sąsaja2, RJ45 10M/100M/1000M self-adaptive Ethernet interface
- Sąsajos
- Serijinė sąsajaRS-232, RS-485 (full-duplex), keyboard
- SATA4 SATA interfaces
- eSATASupport
- TalpaUp to 12 TB capacity for each disk
- Ispėjamojo signalo įvestis/išvestis16/4
- USB sąsaja
Front panel: 2 × USB 2.0
Rear panel: 1 × USB 3.0
- Pagrindinis
- Maitinimas100 to 240 VAC, 50 to 60 Hz
- Energijos sunaudojimas≤ 40 W (without HDD)
- Darbinė temperatūra-10 °C to 55 °C (14 °F to 131 °F)
- Atsparumas drėgmei10% to 90%
- Dydis445 × 400 × 71 mm (17.5 × 15.7 × 2.8 inch)
- Svoris≤ 7 kg (without HDD, 15.4 lb.)
