- Įrašymas
- Vaizdo suspaudimasH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Užkodavimo raiška
When 1080p Lite mode is not enabled:
3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode is enabled:
3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF
- Kadrų dažnis
Main stream:
When 1080p Lite mode not enabled:
For 3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps
For 5 MP stream access: 5 MP lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps
For 4 MP stream access: 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
- Video Bitrate32 Kbps to 6 Mbps
- Dvibugas srautasSupport
- Srauto tipasVideo, Video & Audio
- Garso suspaudimasG.711u
- Garso bitų greitis64 Kbps
- Vaizdas ir garsas
- IP vaizdo įrašų įvestis
8-ch (up to 24-ch)
Up to 6 MP resolution
Support H.265+/H.265/H.264+/H.264 IP cameras
- Analoginė vaizdo įrašų įvestis
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input3K(2960 x 1665)@20 fps, 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps
- AHD Input5 MP(2560 × 1944)@20 fps,4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
- HDCVI Input5 MP(2560 × 1944)@20 fps,4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
- CVBS InputPAL/NTSC
- HDMI išvestis1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA išvestis1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Garso įvestis
1-ch, RCA (2.0 Vp-p, 1 KΩ)
16-ch via coaxial cable
- Garso išvestis1-ch, RCA (Linear, 1 KΩ)
- Dvipusis greitis1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input)
- Sinchroninis atkūrimas16-ch
- Internetas
- Nuotolinis prisijungimas128
- Total Bandwidth128 Mbps
- ProtokolaiTCP/IP, PPPoE, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
- Tinklo sąsaja
1,
RJ45 10/100/1000 Mbps
self-adaptive Ethernet interface
- Sąsajos
- SATA2 SATA interface
- TalpaUp to 10 TB capacity for each disk
- USB sąsajaReal panel: 2 × USB 2.0
- Ispėjamojo signalo įvestis/išvestisN/A
- Pagrindinis
- Maitinimas12 VDC, 1.9 A
- Energijos sunaudojimas≤ 20 W(without HDD)
- Darbinė temperatūra-10 °C to +55 °C (+14 °F to +131 °F)
- Atsparumas drėgmei10% to 90%
- Dydis260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
- Svoris≤ 1.2 kg (2.6 lb)
