- Sąsajos
- Ispėjamojo signalo įvestis/išvestisN/A (optional to support)
- SATA2 SATA interface, up to 12 TB capacity for each disk
- Serijinė sąsajaRS-485 (half-duplex)
- USB sąsajaFront panel: 1 × USB 2.0;Rear panel: 2 × USB 3.0
- Iškodavimas
- Iškodavimo pajėgumasup to 24-ch 1080P@30fps
- Facial Detection
- Facial Detection and CaptureFace picture detection, face picture search；4-ch face picture capture
- Veido atpažinimas
- Veido nuotraukos palyginimas4-ch face picture comparison alarm (HD analog camera)
- Veido paveikslų bibliotekaUp to 16 face picture libraries;HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash.
- Pagrindinis
- Energijos sunaudojimas≤40 W
- Dydis384 × 317 × 52 mm (15.1 × 12.5 × 2.0 inch)
- Maitinimas12 VDC, 3.3 A
- Svoris≤ 2 kg (4.4 lb)
- Atsparumas drėgmei10% to 90%
- Darbinė temperatūra-10 °C to 55 °C (14 °F to 131 °F)
- Judesio aptikimas 2.0
- Žmogaus / transporto priemonės analizėDeep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;Quick search by object or event type is supported;
- Tinklas
- Tinklo sąsaja1, RJ45 10/100/1000 Mbps self-adaptive Ethernet interface
- ProtokolaiTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
- Nuotolinis prisijungimas128
- Total Bandwidth256 Mbps
- Perimetro apsauga
- Žmogaus / transporto priemonės analizėUp to 8-ch (advanced model)
- Įrašymas
- Garso bitų greitis64 Kbps
- Garso suspaudimasG.711u
- Dvibugas srautasSupport main stream or sub stream
- Užkodavimo raiškaWhen 1080p Lite mode is not enabled: 3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF;When 1080p Lite mode is enabled: 3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF
- Kadrų dažnisMain stream:When 1080p Lite mode not enabled: For 3K stream access: 3K lite@12fps;4 MP lite@15fps/1080pLite@20fps;720p/WD1/4CIF/VGA/CIF@20fpsFor 5 MP stream access: 5 MP lite@12fps;4 MP lite@15fps/1080pLite@20fps;720p/WD1/4CIF/VGA/CIF@20fpsFor 4 MP stream access: 4 MP lite@15fps/1080pLite@25fps (P)/30fps (N) ;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)When 1080p Lite mode enabled: 3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)Sub-stream:WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
- Srauto tipasVideo, Video & Audio
- Video Bitrate32 Kbps to 6 Mbps
- Vaizdo suspaudimasH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Vaizdas ir garsas
- AHD Input5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
- Analoginė vaizdo įrašų įvestis16-chBNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- Garso įvestis1-ch, RCA (2.0 Vp-p, 1 KΩ)，16-ch via coaxial cable
- Garso išvestis1-ch, RCA (Linear, 1 KΩ)
- CVBS InputPAL/NTSC
- CVBS išvestis1-ch, BNC (1.0 Vp-p, 75 Ω),resolution: PAL: 704 × 576, NTSC: 704 × 480
- HDCVI Input3K(2880×1620)@25fps, 5MP(2592 × 1944)@20 fps, 4MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
- HDMI išvestis1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- HDTVI Input3K(2960 x 1665)@25/20fps, 3K(3328×1504)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30fps,1080P@25/30 fps, 720P@25/30fps
- IP vaizdo įrašų įvestis8-ch (up to 24-ch), each up to 6MP
- Sinchroninis atkūrimas16-ch
- Dvipusis greitis1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
- VGA išvestis1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Vaizdo išvesties režimasHDMI/VGA simultaneous output
