- Kamera
- Sensorius1/1.8″ Progressive Scan CMOS
- Maks. rezoliucija2688 × 1520
- Min. apšvietimasColor: 0.0001 Lux @ (F1.0, AGC ON),0 Lux with light
- Užrakto greitis1 s to 1/100,000 s
- Kampo keitimasPan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
- Diena&NaktisIR cut filter
- Lęšis
- Focal Length & FOV2.8 mm, horizontal FOV 111.1°, vertical FOV 57.6°, diagonal FOV 138.5°4 mm, horizontal FOV 95.2°, vertical FOV 48.3°, diagonal FOV 117.4°
- Lęšio tipasFixed focal lens, 2.8 and 4 mm optional
- Lęšio montavimasM16
- Rainelės tipasFixed
- DiafragmaF1.0
- Ryškumo gylis2.8 mm: 2.5 m to ∞4 mm: 3.1 m to ∞
- DORI
- DORI2.8 mm: D: 61 m, O: 24 m, R: 12 m, I: 6 m4 mm: D: 75 m, O: 30 m, R: 15 m, I: 7 m
- Apšvietimas
- Papildomo apšviešimo tipasWhite Light,IR
- Papildomo apšvietimo diapazonasUp to 40 m
- Išmanus papildomas apšvietimasYes
- IR bangos ilgis850 nm
- Vaizdas
- Pagrindinis srautas50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Antrinis srautas50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Trečias srautas50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)*Third stream is supported under certain settings.
- Vaizdo suspaudimas Main stream: H.265/H.264/H.265+/H.264+,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264,*Third stream is supported under certain settings.
- Vaizdo bitų greitis32 Kbps to 8 Mbps
- H.264 tipasBaseline Profile,Main Profile,High Profile
- H.265 tipasMain Profile
- Bitų greičio kontrolėCBR,VBR
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)1 fixed region for main stream
- Garso
- Garso tipasMono sound
- Garso bitų greitis64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Garso suspaudimas G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Garso atrankos dažnis8 kHz/16 kHz/32 kHz/48 kHz
- Pašalinių garsų šalinimasYes
- Tinklas
- Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
- Tiesioginis vaizdo žiūrėjimasUp to 6 channels
- APIONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
- Naudotojas/prievadasUp to 32 users3 user levels: administrator, operator, and user
- SaugumasPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
- Vidinė atmintisNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
- KlientasiVMS-4200,Hik-Connect,Hik-Central
- NaršyklėPlug-in free live view: Chrome 80+, Firefox 80+, Edge 89+,Local service: Chrome 80+, Firefox 80+, Edge 89+
- Nuotrauka
- Nuotraukos parametrų keitiklisYes
- Nuotraukos nustatymaiRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Diena/Naktis režimasDay,Night,Auto,Schedule
- Wide Dynamic Range (WDR)130 dB
- SNR≥ 52 dB
- Nuotraukų pagražinimasBLC,HLC,3D DNR,Distortion Correction,Defog
- Vaizdo stabilizavimasEIS
- Privatumo kaukė4 programmable polygon privacy masks
- Sąsaja
- Interneto sąsaja1 RJ45 10 M/100 M self-adaptive Ethernet port
- Vidinė atmintisBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Įmontuotas garsiakalbisMax. power consumption: 2 W, max. sound pressure level: 10 cm: 110 dB.
- GarsoBuilt-in Microphone: Arrayed dual-microphone
- Perkrovimo mygtukasYes
- Funkcijos
- Pagrindinės funkcijosMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
- Išmaniosios funkcijosScene change detection
- SąsajaUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,audible warning,strobe light flashing
- Išmaniosios funkcijos
- Veido atpažinimasYes
- Perimetro apsaugaLine crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)
- Pagrindinis
- Maitinimas12 VDC ± 25%, 1 A, max. 12 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: IEEE 802.3at, Class 4, max. 16 W
- MedžiagaFront cover: Metal, body: Metal, bracket: Metal
- SvorisApprox. 530 g (1.2 lb.)
- Svoris su įpakavimuApprox. 815 g (1.8 lb.)
- DydisØ74.4 mm × 176.3 mm (Ø2.93″ × 6.94″)
- Pakuotės dydis234 mm × 120 mm × 117 mm (9.2″ × 4.7″ × 4.6″)
- Sandėliavimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Darbo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Kalba33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Pagrindinės funkcijosHeartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
- Flashing Light/SRB model: Red and Blue Light/SL model: White Light
- Patvirtinimai
- SaugumasUL: UL 62368-1,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017
- AplinkosaugaCE-RoHS: 2011/65/EU
- EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015
- ApsaugaIP67: IEC 60529-2013
- Apsauga nuo korozijosNEMA 4X (NEMA 250-2018)
