- Patvirtinimai
- Apsauga nuo korozijosNO
- AutomatikaEN50121-4
- EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015
- AplinkosaugaCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
- KitaPVC FREE
- ApsaugaIP67: IEC 60529-2013,IK10: IEC 62262:2002
- SaugumasCB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,LOA: IEC/EN 60950-1
- Garso
- Garso bitų greitis64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Garso atrankos dažnis8 kHz/16 kHz/32 kHz/48 kHz
- Garso tipasMono sound
- Pašalinių garsų šalinimasYes
- Camera
- Diena&NaktisIR cut filter,Blue glass module (less ghost phenomenon)
- Sensorius1/1.8″ Progressive Scan CMOS
- Maks. rezoliucija2688 × 1520
- Min. apšvietimasColor: 0.0005 Lux @ (F1.2, AGC ON),B/W: 0.0001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
- Užrakto greitis1 s to 1/100,000 s
- DORI
- DORIWide：2.8 to 12 mm: D (Detect): 60 m, O (Observe): 23.8 m, R (Recognize): 12 m, I (Identify): 6 m8 to 32 mm: D (Detect): 150.3 m, O (Observe): 59.7 m, R (Recognize): 30.1 m, I (Identify): 15 mTele:2.8 to 12 mm:D (Detect): 151.7 m, O (Observe): 60.2 m, R (Recognize): 30.3 m, I (Identify): 15.2 m8 to 32 mm:D (Detect): 400 m, O (Observe): 158.7 m, R (Recognize): 80 m, I (Identify): 40 m
- Išmaniosios funkcijos
- Meta duomenysIntrusion detection,line crossing detection,region entrance detection,region exiting detection,road traffic
- Perimeter Protection Line crossing, intrusion, region entrance, region exitingSupport alarm triggering by specified target types (human and vehicle)Support combined event alarm triggering
- Kelių eismo ir transporto priemonių aptikimasSmart Function:Support license plate recognition of vehicles and motorcycles (only in checkpoint scenario)Support vehicle attribute detection, including vehicle type, color, brand, driving direction, etc.Support vehicle and non-vehicle countingBlocklist and allowlist: up to 10,000 recordsLPR Countries/Regions:4 areas (Europe, Middle East, Asia-Pacific, Africa) and more than 124 countries/regionsAccuracy (Under recommended installation and lighting conditions):License plate recognition rate ≥98%Capture rate ≥99%Driving direction accuracy rate ≥98%Vehicle Capture Speed:Front installation in checkpoint scenario: up to 120 km/hSide installation: up to 80 km/hCapture Mode: License Plate and Vehicle Mode, Vehicle Priority Mode
- Funkcijos
- Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,video quality diagnosis,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),vibration detection
- SąsajaUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning
- Išmaniosios funkcijosscene change detection,audio exception detection,defocus detection
- Pagrindinis
- Rasos šalinimasYes
- Device ManagementSupports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces
- DydisWith -Y: Ø140 mm × 377.4 mm (Ø5.5″ × 14.9″), Without -Y: Ø144.1 mm × 374.7 mm (Ø5.7″ × 14.8″)
- Pagrindinės funkcijosHeartbeat,anti-banding,one-key reset,mirror,password protection,flash log
- ŠildytuvasYes
- Kalba33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- MedžiagaAluminum alloy body
- Pakuotės dydis425 mm × 190 mm × 180 mm (16.7″ × 7.5″ × 7.1″)
- Maitinimasthree-core terminal block,12 VDC ± 20%, 1.88 A, max. 22.56 W,24 VAC ± 20%, 1.57 A, max. 21.5 W,PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.53 A to 0.4 A, max. 22.6 W
- Darbo sąlygos-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
- Sandėliavimo sąlygos-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing)
- SvorisApprox. 2170 g (4.78 lb.)
- Svoris su įpakavimuApprox. 3364 g (7.42 lb.)
- Apšvietimas
- IR bangos ilgis850 nm
- Išmanus papildomas apšvietimasYes
- Papildomo apšvietimo diapazonas2.8 to 12 mm: Monitoring: 60 m; 8 to 32 mm: Monitoring: 100 m
- Papildomo apšviešimo tipasIR
- Nuotrauka
- Diena/Naktis režimasDay,Night,Auto,Schedule,Alarm Trigger,Video Trigger
- Nuotraukų pagražinimasBLC,HLC,3D DNR,Distortion Correction,Defog
- Nuotraukos parametrų keitiklisYes
- Nuotraukos nustatymaiRotate mode,saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
- Vaizdo stabilizavimasEIS
- Nuotraukos perdangaLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
- Privatumo kaukė8 programmable polygon privacy masks
- SNR≥ 52 dB
- Wide Dynamic Range (WDR)150 dB
- Sąsaja
- Alarm 2 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A)
- Garso1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
- Interneto sąsaja1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
- Vidinė atmintisBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB
- GaliaNO
- RS-485NO
- Perkrovimo mygtukasYes
- Vaizdo išvestis1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
- WiegandNO
- Lęšis
- Diafragma2.8 to 12 mm: F1.38 to F2.53, 8 to 32 mm: F1.7 to F1.73
- Focal Length & FOV2.8 to 12 mm, horizontal FOV 106° to 41.8°, vertical FOV 55.4° to 23.6°, diagonal FOV 130° to 48.1°8 to 32 mm, horizontal FOV 42.5° to 15.2°, vertical FOV 23.4° to 8.7°, diagonal FOV 49.7° to 17.3°
- FokusavimasAuto,Semi-auto,Manual
- Rainelės tipasP-iris
- Mobile Communication
- DažnisNO
- SIM Card TypeNO
- StandartasNO
- Tinklas
- APIISAPI,SDK,ISUP,OTAP,ONVIF (Profile S, Profile G, Profile T, Profile M)
- KlientasiVMS-4200,Hik-Connect,Hik-Central
- Vidinė atmintisNAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- ProtokolaiTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets
- SaugumasPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256
- Tiesioginis vaizdo žiūrėjimasUp to 20 channels
- Naudotojas/prievadasUp to 32 users3 user levels: administrator, operator, and user
- NaršyklėPlug-in required live view: IE 10, IE 11,Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Vaizdas
- Bitų greičio kontrolėCBR,VBR
- Penktasis srautas50 Hz: 25 fps (704 × 576, 640 × 480)60 Hz: 30 fps (704 × 480, 640 × 480)
- Ketvirtas srautas50 Hz: 25 fps (704 × 576, 640 × 480)60 Hz: 30 fps (704 × 480, 640 × 480)
- H.264 tipasBaseline Profile,Main Profile,High Profile
- H.265 tipasMain Profile
- Pagrindinis srautasMonitoring mode:50 Hz: up to 50 fps (2688 × 1520, 1280 × 720), up to 100 fps (1920 × 1080)60 Hz: up to 60 fps (2688 × 1520, 1280 × 720), up to 120 fps (1920 × 1080)*High frame rate is supported under monitoring mode only.smart mode:50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Region of Interest (ROI)4 fixed regions for each stream
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Antrinis srautas50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480)
- Tikslinis apkarpymasYes
- Trečias srautas50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
- Vaizdo bitų greitis32 Kbps to 8 Mbps
- Video Compression Main stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264,Fourth stream: H.265/H.264/MJPEG,Fifth stream: H.265/H.264/MJPEG
- e-PTZSupport Patrol and Auto Tracking settings
