- Kamera
- Sensorius1/1.8″ Progressive Scan CMOS
- Maks. rezoliucija2560 × 1440
- Min. apšvietimasColor: 0.001 Lux @ (F1.4, AGC ON), B/W: 0 Lux with Light
- Užrakto greitis1 s to 1/100,000 s
- Lęšis
- FokusavimasAuto,Semi-auto,Manual
- Lęšio tipasVarifocal lens, motorized lens, 2.8 to 12 mm
- Focal Length & FOV2.8 to 12 mm, horizontal FOV 70.1° to 29.7°, vertical FOV 38.7° to 16.8°, diagonal FOV 81.2° to 34.0°
- DiafragamaF1.4
- DORI
- DORI
Wide: D: 61.5 m, O: 24.4 m, R: 12.3 m, I: 6.2 m
Tele: D: 151.7 m, O: 60.2 m, R: 30.3 m, I: 15.2 m
- Apšvietimas
- Papildomo apšviešimo tipasWhite Light
- Papildomo apšvietimo diapazonas
Turbidity (NTU) : 0 to 5, up to 1 m,
Turbidity (NTU) : 5 to 15, up to 0.5 m,
Turbidity (NTU) : ＞15, up to 0.2 m
- Vaizdas
- Pagrindinis srautas
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
- Antrinis srautas
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
- Trečias srautas
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
- Vaizdo suspaudimas
Main stream: H.265/H.264 /H.265+/H.264+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264
- Vaizdo bitų greitis32 Kbps to 8 Mbps
- H.264 tipasBaseline Profile,Main Profile,High Profile
- H.265 tipasMain Profile
- Bitų greičio kontrolėCBR,VBR
- Scalable Video Coding (SVC)H.265 and H.264 encoding
- Region of Interest (ROI)5 fixed regions for main stream and sub-stream
- Tikslinis apkarpymasYes
- Internetas
- ProtokolaiTCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, SSL/TLS, WebSocket, WebSockets
- Tiesioginis vaizdo žiūrėjimasUp to 20 channels
- APIOpen Network Video Interface, ISAPI, SDK, ISUP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Vidinė atmintis
NAS (NFS, SMB/CIFS),CVR,NVR,Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- KlientasiVMS-4200, Hik-Connect, Hik-Central
- Naršyklė
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Nuotrauka
- Nuotraukos parametrų keitiklisYes
- Nuotraukos nustatymaiRotate mode, saturation, brightness, contrast, sharpness, white balance, AGC, adjustable by client software or web browser
- Diena/Naktis režimasDay,Night,Auto,Schedule,Alarm Trigger
- Wide Dynamic Range (WDR)120 dB
- Nuotraukų pagražinimasBLC,HLC,3D DNR,Defog
- Nuotraukos perdangaLOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
- SNR≥ 50 dB
- Privatumo kaukė8 programmable polygon privacy masks
- Sąsaja
- Interneto sąsaja1 RJ45 10 M/100 M self-adaptive Ethernet port
- Vidinė atmintis
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 128 GB,
*You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing.
- Funkcijos
- Pagrindinės funckcijosMotion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
- Išmaniosios funkcijosLine crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection,object removal detection,scene change detection
- SąsajaUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture
- Pagrindinis
- Sistemos parametrai
36 VDC ± 20%, 0.5 A, max. 18 W, two-core terminal block
PoE: IEEE 802.3at, Class 4
- Medžiaga316L and anti-corrosion coating
- Dydis210.6 mm × 208 mm × 224 mm (8.29″ × 8.19″ × 8.82″)
- Pakuotės dydis700 mm × 530 mm × 365 mm (27.6″ × 20.9″ × 14.4″)
- SvorisApprox. 13.47 kg (29.69 lb.)
- Svoris su įpakavimuApprox. 17.38 kg (38.32 lb.)
- Darbo sąlygos-10 °C to 60 °C (14 °F to 140 °F). Humidity 100% or less (non-condensing)
- Kalba33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Pagrindinės funkcijosAnti-banding, heartbeat, mirror, flash log, password reset via email, pixel counter
- Cable Length15 m (49.2 ft.) (included)
- Patvirtinimai
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
- Saugumas
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1
- ApsaugaIP68 (IEC 60529-2013) (within 15 m underwater)
