- Kamera
- Sensorius1/3″ Progressive Scan CMOS
- Maks. rezoliucija2688 × 1520
- Min. apšvietimas
2 mm: color: 0.006 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR
2.8 mm and 4 mm: color: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR
- Užrakto greitis1/3 s to 1/100,000 s
- Day & NightIR cut filter
- Kampo keitimasPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
- Lęšis
- Focal Length & FOV
2 mm, horizontal FOV 128.4°, vertical FOV 75.4°, diagonal FOV 147.1°
2.8 mm, horizontal FOV 102.7°, vertical FOV 55.2°, diagonal FOV 122.5°
4 mm, horizontal FOV 82.8°, vertical FOV 45.3°, diagonal FOV 97.7°
- Diafragama
2 mm: F2.0
2.8 mm: F1.4
4 mm: F1.4
- Lęšio montavimasM12
- DORI
- DORI
2 mm: D: 45.5 m, O: 18.0 m, R: 9.1 m, I: 4.5 m
2.8 mm: D: 64.2 m, O: 25.5 m, R: 12.8 m, I: 6.4 m
4 mm: D: 77.4 m, O: 30.7 m, R: 15.5 m, I: 7.7 m
- Apšvietimas
- IR distancijaUp to 10 m
- Bangos ilgis850 nm
- Išmanus papildomas apšvietimasYes
- Vaizdas
- Pagrindinis srautas
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Trečias srautas
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Vaizdo suspaudimas
Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
- Vaizdo bitų greitis32 Kbps to 8 Mbps
- H.264 tipasBaseline Profile/Main Profile/High Profile
- H.265 tipasMain Profile
- Bitų greičio kontrolėCBR/VBR
- Scalable Video Coding (SVC)
Yes
- Region of Interest (ROI)1 fixed region for main stream and sub-stream
- Garsas
- Pašalinių garsų šalinimasYes
- Garso atrankos dažnis8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Garso suspaudimasG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Garso bitų greitis64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 Kbps to 192 Kbps (MP2L2)/8 Kbps to 320 Kbps (MP3)
- Internetas
- Tiesioginis vaizdo žiūrėjimasUp to 6 channels
- APIOpen Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
- ProtokolaiTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, QoS, 802.1X, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
- User/HostUp to 32 users. 3 user levels: administrator, operator and user
- SaugumasPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
- Vidinė atmintisNAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- KlientasiVMS-4200, Hik-Connect, Hik-Central
- Naršyklė
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Nuotrauka
- Wide Dynamic Range (WDR)120 dB
- Diena/Naktis režimasDay, Night, Auto, Schedule
- Nuotraukų pagražinimasBLC, HLC, 3D DNR
- Nuotraukos parametrų keitiklisYes
- Nuotraukos nustatymaiRotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
- Transducer
- PIR AngleHorizontal: 90°, vertical: 80°
- PIR RangeUp to 8 m
- Sąsaja
- Įmontuotas mikrofonasYes
- Įmontuotas garsiakalbisPower: 1 W. Max. sound pressure level: 10 cm: 91 dB.
- Saugyklos vietaBuilt-in memory card slot, support microSD/SDHC/SDXC card, up to 512 GB
- Įrenginio nustatymas iš naujoYes
- Bendravimo sąsaja1 RJ45 10 M/100 M self-adaptive Ethernet port
- Funkcijos
- Pagrindinės funckcijosMotion detection, video tampering alarm, exception
- Išmaniosios funkcijosScene change detection
- SąsajaUpload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email, audible warning
- Išmaniosios funkcijos
- Veido atpažinimasYes
- Perimetro apsauga
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
- Pagrindinis
- Sistemos parametrai
12 VDC ± 25%, 0.5 A, max. 6.0 W, Ø5.5 mm coaxial power plug
PoE: (802.3af, Class 3, 36 V to 57 V), 0.2 A to 0.13 A, max. 7.0 W
- Tinklo naršyklės kalba
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Pagrindinės funkcijosAnti-flicker, heartbeat, password reset via email, pixel counter
- Sandėliavimo sąlygos-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
- Darbo sąlygos-10 °C to 40 °C (14 °F to 104 °F). Humidity 95% or less (non-condensing)
- Medžiaga iš kurios padaryta kameraPlastic
- Kameros dydis
2.8 mm and 4 mm: 102.9 mm × 65.2 mm × 32.6 mm (4.1″ × 2.6″ × 1.3″)
2 mm: 102.9 mm × 65.2 mm × 28.8 mm (4.1 × 2.6″ × 1.1″) „
- Pakuotės dydis150 mm × 125 mm × 99 mm (5.9″ × 4.9″ × 3.9″)
- Kameros svorisApprox. 120 g (0.3 lb.)
- Svoris su įpakavimuApprox. 430 g (0.9 lb.)
- Patvirtinimai
- EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014);
KC (KN 32: 2015, KN 35: 2015)
- Saugumas
UL (UL 62368-1);
CB (IEC 62368-1:2014+A11);
CE-LVD (EN 62368-1:2014/A11:2017)
- Aplinkosauga
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
