- Termovizorio modulis
- SensoriusVanadium Oxide Uncooled Focal Plane Arrays
- Rezoliucija384 x 288
- Taškinis žingsnis17 μm
- Spektrinis diapazonas8 μm to 14 μm
- FOV25 mm
- IFOV0.68 mrad
- DiafragamaF1.0
- FOV14.9° × 11.2° (H × V)
- Minimali fokusavimo distancija13 m
- Skaitmeninis priartinimas×2, ×4
- Optinis modulis
- Sensorius1/2.7″ Progressive Scan CMOS
- Rezoliucija 2688 × 1520
- Min. apšvietimas0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR
- FOV25.25° × 14.44° (H × V)
- FOV12mm
- Užrakto greitis1 s to 1/100,000 s
- Baltos spalvos balansasMWB/AWB1/Locked WB/Fluorescent Lamp/Incandescent Lamp/Warm Light Lamp/Natural Light
- Day & Night ModeIR Cut Filter with Auto Switch
- WDR120 dB
- DiafragamaF 1.6
- Vaizdo efektas
- Bi-spectrum Image FusionDisplay the details of optical channel on thermal channel
- Picture in Picture Display partial image of thermal channel on the full screen of optical channel
- Tikslinė spalvaYes. Supported in white hot and black hot mode.
- Apšvietimas
- IR distancija Up to 100 m
- IR intensyvumas ir kampasAutomatically adjusted
- Išmanioji funkcija
- VCA4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.
- Temperatūros matavimas3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line)
- Temperatūros diapazonas-20 °C to 150 °C (-4 °F to 302 °F)
- Temperatūros tikslumas ± 8 °C (±14.4 °F)
- Vaizdas ir garsas
- Pagrindinis srautas
Optical channel
50 HZ: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 HZ: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Thermal channel
25 fps (1280×720P， 704×576， 352×288， 384×288)
- Sub-stream
Optical channel
50 HZ: 25 fps (704 × 576, 352 × 288)
60 HZ: 30 fps (704 × 480, 352 × 240)
Thermal channel
25 fps (704 × 576, 352 × 288, 384 × 288)
- Vaizdo suspaudimas
Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
- Garso suspaudimasG.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM
- Internetas
- Protokolai IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE,TP,Bonjour,SFTP,SRTP,SSL
- Vidinė atmintisMicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
- APIISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface,ONVIF (Profile S, Profile G)
- Tiesioginis vaizdo žiūrėjimasUp to 20 channels
- User/Host levelUp to 32 users, 3 levels: Administrator, Operator, User
- SaugumasUser authentication (ID and password), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering
- Klientas iVMS-4200, Hik-Connect
- Sąsaja
- Signalizacijos įvestis2, alarm input (0-5 VDC)
- Signalizacijos išvestis2, alarm output (alarm response actions configurable)
- Alarm ActionSD recording/Relay output/Smart capture/FTP upload/Email linkage
- Garso įvestis
1, 3.5 mm Mic in/Line in interface
Line input: 2 – 2.4 V [p-p], output impedance: 1 KΩ ± 10%
- Garso išvestis Linear level, impedance: 600 Ω
- Bendravimo sąsaja
1, RJ45 10 M/100 M Self-adaptive Ethernet interface.
1, RS-485 interface (half duplex)
- Analoginė išvestis1.0V [p-p]/75Ω, PAL/NTSC/BNC
- Pagrindinis
- Kalbos32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
- Maitinimas
24 VAC ± 25%, 12 VDC ± 25%,24VDC two-core terminal block
PoE (802.3af, class 3)
- Energijos sunaudojimas
24 VAC ± 25%: 0.8 A to 0.5 A, max. 9.5 W
12 VDC ± 25%: 0.63 A to 1.06 A, max. 9 W
24VDC: 0.4A, max 9.5W
PoE (802.3af, class 3): 36 V to 57 V, 0.28 A to 0.17 A, max. 10 W
- Darbinė temperatūra / drėgmė
Temperature: -40°C to 65°C (-40°F to 149°F)
Humidity: 95% or less
- Apsaugos lygis
IP67 Standard
TVS 4000V lightning protection, surge protection, voltage transient protection
IK10-rated housing
- Dydis376.1 mm × 119.1 mm × 118.1 mm (14.81″ × 4.68″ × 4.65″)
- Svoris1.82 kg (4.01 lb)
