Belaidžio ryšio režimas802.11b/g/n (Wi-Fi 4), Access Point (AP), Station (STA)
Wi-Fi securityWPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnect, 802.11w Protected Management Frames (PMF)
SSID/ESSIDESSID stealth mode
Wi-Fi usersUp to 50 simultaneous connections
Wireless Connectivity FeaturesWireless mesh (802.11s), fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k)
Wireless MAC filterAllowlist, blocklist
Wireless QR code generatorOnce scanned, a user will automatically enter your network without needing to input login information
TravelMateForward Wi-Fi hotspot landing page to a subsequent connected device
WAN1 x WAN port 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
LAN1 x LAN port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
MaršrutasStatic routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
Interneto protokolaiTCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN
VoIP praėjimo paramaH.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
Ryšio stebėjimasPing Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
UgniasienėPort forward, traffic rules, custom rules, TTL target customization
Ugniasienės būsenos puslapisView all your Firewall statistics, rules, and rule counters
Prievadų valdymasView device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on
Tinklo topologijaVisual representation of your network, showing which devices are connected to which other devices
DHCPStatic and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards
QoS / išmanusis eilių valdymas (SQM)Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
DDNSSupported >25 service providers, others can be configured manually
DNS per HTTPSDNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS
Tinklo atsarginės kopijosWi-Fi WAN, VRRP, Wired options, each of which can be used as an automatic Failover
Apkrovos balansavimasBalance Internet traffic over multiple WAN connections
Viešosios interneto prieigos taškasCaptive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorization, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customizable themes and optionality to upload and download customized hotspot themes
SSHFSPossibility to mount remote file system via SSH protocol
Eismo valdymasReal-time monitoring, wireless signal charts, traffic usage history
AutentifikavimasPre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator
UgniasienėPreconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64
Įsilaužimo prevencijaDDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
VLANPort and tag-based VLAN separation
WEB filtrasBlacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
Prieigos kontrolėFlexible access control of SSH, Web interface, CLI and Telnet
SSL certificate generationLet’s Encrypt and SCEP certificate generation methods
802.1xPort-based network access control server
OpenVPNMultiple clients and a server can run simultaneously, 27 encryption methods
OpenVPN šifravimas27 encryption methods including DES-CBC 64, RC2-CBC 128, AES-128-GCM 128, AES-256-CBC 256, etc.
IPsecXFRM, IKEv1, IKEv2, 14 encryption methods for IPsec (3DES, AES128, AES256, AES256GCM16, etc.)
GREGRE tunnel, GRE tunnel over IPsec support
PPTP, L2TPClient/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support
StunnelProxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code
DMVPNMethod of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub support
SSTPSSTP client instance support
ZeroTierZeroTier VPN client support
WireGuardWireGuard VPN client and server support
TincTinc offers encryption, authentication and compression in its tunnels. Client and server support.
OPC UASupported modes: Client, Server
MODBUSSupported modes: Server, Client; Supported connection types: TCP
Pasirinktiniai registraiMODBUS TCP custom register block requests, which read/write to a file inside the router
Palaikomi duomenų formatai8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII
ProtokolaiHTTP(S), MQTT, Azure MQTT
Data to serverExtract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting
MQTT GatewayModbus MQTT Gateway allows sending commands and receiving data from MODBUS Server through MQTT broker
Monitoring & ManagementWEB UI: HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, firmware update notifications
FOTAFirmware update from server, automatic notification
SSHSSH (v1, v2)
El. paštasReceive email message status alerts of various services
TR-069Supported TR-069 clients such as OpenACS, EasyCwmp, ACSLite, GenieACS, FreeACS, LibCWMP, and others
MQTTMQTT Broker, MQTT publisher
SNMPSNMP (v1, v2, v3), SNMP Trap, Brute force protection
JSON-RPCManagement API over HTTP/HTTPS
RMSTeltonika Remote Management System (RMS)
ProcesoriusMediatek, 580 MHz, MIPS 24KEc
RAM128 MB, DDR2
FLASH saugykla16 MB serial NOR flash
Operacinė sistemaRutOS (OpenWrt based Linux OS)
KalbosBusybox shell, Lua, C, C++
Maitinimo jungtis3-pos plugable terminal block
Įeinančios įtampos diapazonas9-30 VDC, reverse polarity protection, surge protection >31 VDC 10us max
PoE (pasyvus)Passive PoE over spare pairs, 9 – 30 VDC
Energijos sunaudojimasIdle: < 1 W / Max: < 2 W
Tinklas2 x RJ45 ports, 10/100 Mbps
LED indikatoriai1 x WAN type LED, 1 x LAN type LED, 1 x Power LED
Sistemos parametrai1 x 3-pin power connector
Antenos1 x RP-SMA for Wi-Fi
PerkrovimasReboot/User default reset/Factory reset button
KorpusasAluminium housing
Dydis113.10 x 25 x 68.6 mm
Svoris142.3 g
MontavimasIntegrated DIN rail bracket, wall mount, flat surface (additional kit needed)
Darbinė temperatūra-40 °C to 75 °C
Drėgmė10% to 90% non-condensing
IP reitingasIP30
Reguliavimo patvirtinimaiCE, UKCA, RCM, FCC, IC, CB, WEEE, RoHS, REACH
